AMD Ryzen 5 8500G Processor with Radeon Graphics - 100-100000931BOX

The AMD Ryzen 5 8500G processor comes with AMD Radeon 740M graphics built in for your everyday gaming and PC needs. The CPU is powered by Zen4 architecture and comes with 6 cores and 12 Threads.
Specification:

Model    AMD Ryzen 5 8500G
Platform    Desktop
Product Family    AMD Ryzen Processors
Product Line    AMD Ryzen 5 8000 G-Series Desktop Processors with Radeon Graphics
AMD PRO Technologies    No
Consumer Use    Yes
Regional Availability    Global
Former Codename    "Phoenix"
Architecture    2 x "Zen4", 4 x "Zen4c"
# of CPU Cores    6
Multithreading (SMT)    Yes
# of Threads    12
Max. Boost Clock    Up to 5.0GHz
Base Clock    3.5GHz
Max Zen4c Clock    Up to 3.7GHz
Zen4 Base Clock    4.1GHz
Zen4c Base Clock    3.2GHz
L2 Cache    6MB
L3 Cache    16MB
Default TDP    65W
AMD Configurable TDP (cTDP)    45-65W
Processor Technology for CPU Cores    TSMC 4nm FinFET
CPU Compute Die (CCD) Size    137mm²
Package Die Count    1
Unlocked for Overclocking    Yes
AMD EXPO Memory Overclocking Technology    Yes
Precision Boost Overdrive    Yes
Curve Optimizer Voltage Offsets    Yes
AMD Ryzen Master Support    Yes
CPU Socket    AM5
CPU Boost Technology    Precision Boost 2
Instruction Set    x86-64
Supported Extensions    AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
Max. Operating Temperature (Tjmax)    95°C
*OS Support    Windows 11 - 64-Bit Edition
Windows 10 - 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.
Connectivity
Native USB 4 (40Gbps) Ports    2
Native USB 3.2 Gen 2 (10Gbps) Ports    2
Native USB 2.0 (480Mbps) Ports    1
PCI Express Version    PCIe 4.0
Native PCIe Lanes (Total/Usable)    14 / 10
NVMe Support    Boot, RAID0, RAID1
System Memory Type    DDR5
Memory Channels    2
Max. Memory    256GB
System Memory Subtype    UDIMM
Max Memory Speed
2x1R   DDR5-5200
2x2R   DDR5-5200
4X1R   DDR5-3600
4x2R    DDR5-3600
Graphics Capabilities
Integrated Graphics    Yes
Graphics Model    AMD Radeon 740M
Graphics Core Count    4
Graphics Frequency    2800 MHz
DirectX Version    2.1
DisplayPort Extensions
HDR Metadata
Adaptive-Sync
UHBR10
DisplayPort Max Refresh Rates (SDR)
7680x4320 @ 60Hz
3840x2160 @ 240Hz
3440x1440 @ 360Hz
2560x1440 @ 480Hz
1920x1080 @ 600Hz
DisplayPort Max Refresh Rates (HDR)
7680x4320 @ 60Hz
3840x2160 @ 240Hz
3440x1440 @ 360Hz
2560x1440 @ 480Hz
1920x1080 @ 600Hz
HDMI Version    2.1
HDCP Version Supported    2.3
USB Type-C DisplayPort Alternate Mode    Yes
Multi-Monitor Support    Yes
Max Displays    4
AMD FreeSync    Yes
Wireless Display    Miracast
Max Video Encode Bandwidth (SDR)    1080p630 8bpc H.264, 1440p373 8bpc H.264, 2160p175 8bpc H.264, 1080p630 8bpc H.265, 1440p373 8bpc H.265, 2160p175 8bpc H.265, 4320p43 8bpc H.265, 1080p864 8/10bpc AV1
1440p513 8/10bpc AV1, 2160p240 8/10bpc AV1
4320p60 8/10bpc AV1
Max Video Decode Bandwidth    1080p60 8bpc MPEG2, 1080p60 8bpc VC1, 1080p786 8/10bpc VP9, 2160p196 8/10bpc VP9
4320p49 8/10bpc VP9, 1080p1200 8bpc H.264
2160p300 8bpc H.264, 4320p75 8bpc H.264
1080p786 8/10bpc H.265, 2160p196 8/10bpc H.265
4320p49 8/10bpc H.265, 1080p960 8/10bpc AV1
2160p240 8/10bpc AV1, 4320p60 8/10bpc AV1
AMD SmartAccess Memory    Yes
Warranty    3 Years
