AMD Ryzen 5 9600X Processor with Radeon Graphics -100-100001405WOF

AMD Ryzen 5 9600X is a high-performance desktop processor that supports DDR5 memory and comes with AMD Radeon graphics, latest Zen 5 architecture and AM5 socket. This processor designed for gaming.
Specification:

Model    AMD Ryzen 5 9600X
Family    Ryzen
Series    Ryzen 9000 Series
Form Factor    Desktops , Boxed Processor
AMD PRO Technologies    No
Consumer Use    Yes
Regional Availability    Global
Former Codename    Granite Ridge AM5
Architecture    Zen 5
# of CPU Cores    6
Multithreading (SMT)    Yes
# of Threads    12
Max. Boost Clock    Up to 5.4 GHz
Base Clock    3.9 GHz
L1 Cache    480 KB
L2 Cache    6 MB
L3 Cache    32 MB
Default TDP    65W
Processor Technology for CPU Cores    TSMC 4nm FinFET
Processor Technology for I/O Die    TSMC 6nm FinFET
Package Die Count    2
Unlocked for Overclocking    Yes
AMD EXPO Memory Overclocking Technology    Yes
Precision Boost Overdrive    Yes
Curve Optimizer Voltage Offsets    Yes
AMD Ryzen Master Support    Yes
CPU Socket    AM5
Supporting Chipsets    A620 , X670E , X670 , B650E , B650 , X870E , X870
CPU Boost Technology    Precision Boost 2
Instruction Set    x86-64
Supported Extensions    AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64
Thermal Solution (PIB)    Not Included
Recommended Cooler    Premium air cooler recommended for optimal performance
Max. Operating Temperature (Tjmax)    95°C
*OS Support    Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit
Connectivity
Native USB 3.2 Gen 2 (10Gbps) Ports    4
Native USB 2.0 (480Mbps) Ports    1
PCI Express Version    PCIe 5.0
Native PCIe Lanes (Total/Usable)    28 , 24
Additional Usable PCIe Lanes from Motherboard    X870E 8x Gen4
X870 4x Gen4
X670E 12x Gen4
X670 12x Gen4
B650E 8x Gen4
B650 8x Gen4
NVMe Support    Boot , RAID0 , RAID1 , RAID5 , RAID10
System Memory Type    DDR5
Memory Channels    2
Max. Memory    192 GB
System Memory Subtype    UDIMM
Max Memory Speed    2x1R DDR5-5600
2x2R DDR5-5600
4x1R DDR5-3600
4x2R DDR5-3600
ECC Support    Yes (Requires mobo support)
Graphics Capabilities
Graphics Model    AMD Radeon Graphics
Graphics Core Count    2
Graphics Frequency    2200 MHz
USB Type-C DisplayPort Alternate Mode    Yes
Key Features
Supported Technologies    AMD EXPO Technology , AMD Ryzen Technologies
Warranty    3 Years
