AMD Ryzen 7 8700G Processor with Radeon Graphics 100-100001236BOX
AMD Ryzen 7 8700G Processor with Radeon Graphics 100-100001236BOX
SKU : 100-100001236BOX
Get it between -
The AMD Ryzen 7 8700G processor comes with AMD Radeon 780M graphics built in to get you in the game, no graphics card necessary. It is powered by zen 4 architecture and comes with 8 cores and 16 threads.
Specification:
Model AMD Ryzen 7 8700G
Platform Desktop
Product Family AMD Ryzen Processors
Product Line AMD Ryzen 7 8000 G-Series Desktop Processors with Radeon Graphics
AMD PRO Technologies No
Consumer Use Yes
Regional Availability Global
Former Codename "Phoenix"
Architecture "Zen 4"
# of CPU Cores 8
Multithreading (SMT) Yes
# of Threads 16
Max. Boost Clock Up to 5.1GHz
Base Clock 4.2GHz
L2 Cache 8MB
L3 Cache 16MB
Default TDP 65W
AMD Configurable TDP (cTDP) 45-65W
Processor Technology for CPU Cores TSMC 4nm FinFET
CPU Compute Die (CCD) Size 178mm²
Package Die Count 1
Unlocked for Overclocking Yes
AMD EXPO™ Memory Overclocking Technology Yes
Precision Boost Overdrive Yes
Curve Optimizer Voltage Offsets Yes
AMD Ryzen™ Master Support Yes
CPU Socket AM5
CPU Boost Technology Precision Boost 2
Instruction Set x86-64
Supported Extensions AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
Max. Operating Temperature (Tjmax) 95°C
*OS Support Windows 11 - 64-Bit Edition
Windows 10 - 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.
Connectivity
Native USB 4 (40Gbps) Ports 2
Native USB 3.2 Gen 2 (10Gbps) Ports 2
Native USB 2.0 (480Mbps) Ports 1
PCI Express Version PCIe 4.0
Native PCIe Lanes (Total/Usable) 20 / 16
NVMe Support Boot, RAID0, RAID1
System Memory Type DDR5
Memory Channels 2
Max. Memory 256GB
System Memory Subtype UDIMM
Max Memory Speed
2x1R DDR5-5200
2x2R DDR5-5200
4X1R DDR5-3600
4x2R DDR5-3600
Graphics Capabilities
Integrated Graphics Yes
Graphics Model AMD Radeon 780M
Graphics Core Count 12
Graphics Frequency 2900 MHz
DirectX Version 2.1
DisplayPort Extensions
HDR Metadata
Adaptive-Sync
UHBR10
DisplayPort Max Refresh Rates (SDR)
7680x4320 @ 60Hz
3840x2160 @ 240Hz
3440x1440 @ 360Hz
2560x1440 @ 480Hz
1920x1080 @ 600Hz
DisplayPort Max Refresh Rates (HDR)
7680x4320 @ 60Hz
3840x2160 @ 240Hz
3440x1440 @ 360Hz
2560x1440 @ 480Hz
1920x1080 @ 600Hz
HDMI Version 2.1
HDCP Version Supported 2.3
USB Type-C DisplayPort Alternate Mode Yes
Multi-Monitor Support Yes
Max Displays 4
AMD FreeSync Yes
Wireless Display Miracast
Max Video Encode Bandwidth (SDR) 1080p630 8bpc H.264, 1440p373 8bpc H.264, 2160p175 8bpc H.264, 1080p630 8bpc H.265, 1440p373 8bpc H.265, 2160p175 8bpc H.265, 4320p43 8bpc H.265, 1080p864 8/10bpc AV1, 1440p513 8/10bpc AV1, 2160p240 8/10bpc AV1, 4320p60 8/10bpc AV1
Max Video Decode Bandwidth 1080p60 8bpc MPEG2, 1080p60 8bpc VC1, 1080p786 8/10bpc VP9, 2160p196 8/10bpc VP9, 4320p49 8/10bpc VP9, 1080p1200 8bpc H.264, 2160p300 8bpc H.264, 4320p75 8bpc H.264, 1080p786 8/10bpc H.265, 2160p196 8/10bpc H.265, 4320p49 8/10bpc H.265, 1080p960 8/10bpc AV1, 2160p240 8/10bpc AV1, 4320p60 8/10bpc AV1
AMD SmartAccess Memory Yes
AI Engine Capabilities
Brand Name AMD Ryzen AI
AMD Ryzen AI Available
Performance Up to 16 TOPS
Warranty 3 Years
