Intel Core i7 processor 14700K 33M Cache up to 5.60 GHz - BX8071514700K

Intel Core i7-14700K processor is Compatible with Intel 600-series (with potential BIOS update) and 700-series chipset-based motherboards. It supports DDR4 and DDR5 Memory.
Specification:

Model    i7-14700K
Product Collection    Intel® Core™ i7 Processors (14th gen)
Code Name    Products formerly RAPTOR LAKE
Vertical Segment    Desktop
Lithography    Intel 7
Use Conditions    PC/Client/Tablet, Workstation
CPU Specifications
Total Cores    20
# of Performance-cores    8
# of Efficient-cores    12
Total Threads    28
Max Turbo Frequency    5.6 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency ‡    5.6 GHz
Performance-core Max Turbo Frequency    5.5 GHz
Efficient-core Max Turbo Frequency    4.3 GHz
Performance-core Base Frequency    3.4 GHz
Efficient-core Base Frequency    2.5 GHz
Cache    33 MB Intel® Smart Cache
Total L2 Cache    28 MB
Processor Base Power    125 W
Maximum Turbo Power    253 W
Supplemental Information
Marketing Status    Launched
Launch Date    Q4'23
Embedded Options Available    No
Memory Specifications
Max Memory Size (dependent on memory type)    192 GB
Memory Types    Up to DDR5 5600 MT/s
Up to DDR4 3200 MT/s
Max # of Memory Channels    2
Max Memory Bandwidth    89.6 GB/s
ECC Memory Supported ‡    Yes
GPU Specifications
Processor Graphics ‡    Intel® UHD Graphics 770
Graphics Base Frequency    300 GHz
Graphics Max Dynamic Frequency    1.6 GHz
Graphics Output    eDP 1.4b, DP 1.4a, HDMI 2.1
Execution Units    32
Max Resolution (HDMI)‡    4096 x 2160 @ 60Hz
Max Resolution (DP)‡    7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel)‡    5120 x 3200 @ 120Hz
DirectX* Support    12
OpenGL* Support    4.5
OpenCL* Support    3.0
Multi-Format Codec Engines    2
Intel® Quick Sync Video    Yes
Intel® Clear Video HD Technology    Yes
Device ID    0xA780
Expansion Options
Direct Media Interface (DMI) Revision    4.0
Max # of DMI Lanes    8
Scalability    1S Only
PCI Express Revision    5.0 and 4.0
PCI Express Configurations ‡    Up to 1x16+4, 2x8+4
Max # of PCI Express Lanes    20
Package Specifications
Sockets Supported    FCLGA1700
Max CPU Configuration    1
Thermal Solution Specification    PCG 2020A
TJUNCTION    100°C
Package Size    45.0 mm x 37.5 mm
Advanced Technologies
Intel® Gaussian & Neural Accelerator    3.0
Intel® Thread Director    Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU    Yes
Intel® Speed Shift Technology    Yes
Intel® Turbo Boost Max Technology 3.0 ‡    Yes
Intel® Turbo Boost Technology ‡    2.0
Intel® Hyper-Threading Technology ‡    Yes
Intel® 64 ‡    Yes
Instruction Set    64-bit
Instruction Set Extensions    Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle States    Yes
Enhanced Intel SpeedStep® Technology    Yes
Thermal Monitoring Technologies    Yes
Intel® Volume Management Device (VMD)    Yes
Security & Reliability
Intel® Standard Manageability (ISM) ‡    Yes
Intel® Control-Flow Enforcement Technology    Yes
Intel® AES New Instructions    Yes
Secure Key    Yes
Intel® OS Guard    Yes
Execute Disable Bit ‡    Yes
Intel® Boot Guard    Yes
Mode-based Execute Control (MBEC)    Yes
Intel® Virtualization Technology (VT-x) ‡    Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡    Yes
Intel® VT-x with Extended Page Tables (EPT) ‡    Yes
Warranty    3 Years
