MSI MEG Ai1300P PCIE5 1300 Watt 80 Plus Platinum SMPS

MSI MEG Ai1300P is a 1300 watt 80 Plus Gold Fully Modular SMPS. It has active PFC Design and also Supports Nvidia® GeForce RTXTM 40 Series graphics cards.
Features:

Supports Nvidia® GeForce RTXTM 40 Series graphics cards

ATX 3.0 fully supported

PCIe 5.0 ready, with native 16 pin connector

Software sync with MSI center

Full modular design

Sleeve cables

80 PLUS Platinum certified for high efficiency

100% all Japanese 105oC capacitor

Active PFC design

Industrial level protection with OVP,OCP,OPP,OTP, SCP,UVP

LLC Half Bridge Topology with DC-DC module design

ATX 3.0 compatible

It has an output port that is compliant with PCIe 5.0 and Intel PSDG (Power Supply Design Guide) ATX 3.0, also the power supply can hold up to 2x total power excursion and 3x GPU power excursion.

level up your GAME

With native 16 PIN PCIe connector this power supply is ready for Nvidia® GeForce RTX® 40 Series graphics cards. It can freely pipe up to 600W of power to PCIe 5.0 graphics cards.

80 PLUS platinum CERTIFIED

The efficiency of your power supply directly influences your system’s performance and your power consumption. The 80 PLUS Platinum certification promises lower energy consumption and higher efficiency.

GPU SUPPORT FOR ALL

The power supply can support the NVIDIA and AMD graphics cards. Prepared for the highest of requirements, the MEG power supply’s IO supports can support different and versatile ways of connection according to the power connector design of different graphics cards.

compact sizing

Compared with the general platinum power supply on the market. The power supply’s 160mm-long and 150mm-wide dimensions ensure a comfortable and easy fit in most PC cases, effectively providing more space for cable management and airflow to the rest of the system.

sleeve cable

Flexible triple-layer sleeved cables are easy to bend and durable, providing easy cable routing and better durability. It also looks better depending on the preference of users.

Specifications:

Efficiency Rating    80 PLUS Platinum (up to 92%)
Modular    Yes (fully modular)
Fan Size    120 mm
Fan Bearing    Hydro Dynamic Bearing
Dimensions (DxWxH)    160 x 150 x 86 mm
PFC Type    Active PFC
Input Voltage Range    100-240~
Power Watt    1300W
Power Excursion    2600W (*up to 200% of the PSU's rated power for 100μs)
Input Frequency Range    50~60 Hz
Protection    OCP / OVP / OPP / OTP / SCP / UVP
ATX (24 pin)    1
EPS (8 pin)    1
EPS (4+4 pin)    1
PCI-E 5.0 (16 pin)    1 (650W)
PCI-E (6+2 pin)    8
SATA (15 pin)    16
MOLEX (4 pin)    4
FDD (4 pin)    1
Warranty     10 Years
